JUAL ALTERNATOR DELCOREMY
Delco Remy Heavy Duty Alternators
Delco Remy Alternator Models
Already know what product you are looking for? Head to visit the e-catalog to find your part number.
22SI™ HP Brush Type Alternator
| Performance Output | 12 Volt 150 Amps |
| Maximum Speed | 10,000 RPM Continuous 12,000 RPM Intermittent |
| Rotation | Clockwise |
| Temperature Rating | 93°C / 200°F |
| Mounting | J180 Hinge Pad |
| Polarity | Negative Ground |
| Efficiency | 57 % |
| Weight | 14.1 lbs / 6.4 kg |
| Stator Diameter | 5.67 in / 144 mm |
| Length | 8.54 in / 217 mm |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
24SI™ Brush Type Alternator
| Performance Output | 12 Volt 160 Amps 24 Volt 70 Amps |
| Maximum Speed | 10,000 RPM Continuous 12,000 RPM Intermittent |
| Rotation | Clockwise |
| Temperature Rating | 105°C / 221°F |
| Mounting | J180 Hinge Pad |
| Polarity | Negative Ground |
| Efficiency | 12 Volt 62% 24 Volt 72% |
| Weight | 16.2 lbs / 7.7 kg |
| Stator Diameter | 5.67 in / 144 mm |
| Length | 9.22 in / 234.1 mm |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
28SI™ Brush Type Alternator
| Performance Output | 12 Volt 160, 180, & 200 Amps 24 Volt 110 Amps |
| Maximum Speed | 10,000 RPM Continuous 12,000 RPM Intermittent |
| Rotation | Clockwise |
| Temperature Rating | 125°C / 257°F |
| Mounting | J180 Short Hinge J180 Long Hinge Pad |
| Polarity | Negative Ground |
| Efficiency | 12 Volt 66% 24 Volt 76% |
| Weight | 18.7 lbs / 8.5 kg |
| Stator Diameter | 5.67 in / 144 mm |
| Length | 9.27 in / 235.6 mm |
| Remote Sense | Standard |
| Warranty *(US /Canada Only) |
1 year / unlimited miles 2 year / unlimited miles – School Bus |
33SI™ Brushless Type Alternator
| Performance Output | 12 Volts 110 & 135 Amps 24 Volts 75 & 100 Amps |
| Maximum Speed | 10,000 RPM Continuous 12,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 93°C / 200°F |
| Mounting | J180 Hinge |
| Polarity | Negative Ground (Standard) Isolated Ground (Available) |
| Efficiency | 60% |
| Weight | 24.5 lbs / 11.1 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 10.35 in / 263 mm |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
34SI™ Brushless Type Alternator
| Performance Output | 12 Volts 110 & 135 Amps 24 Volts 75 & 100 Amps |
| Maximum Speed | 10,000 RPM Continuous 12,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 93°C / 200°F |
| Mounting | Quad Pad |
| Polarity | Negative Ground (Standard) Isolated Ground (Available) |
| Efficiency | 60% |
| Weight | 25.4 lbs / 11.5 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 10.35 in / 263 mm |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
35SI™ Brushless Type Alternator
| Performance Output | 12 Volts 110 & 135 Amps |
| Maximum Speed | 10,000 RPM Continuous 12,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 105°C / 221°F |
| Mounting | J180 Hinge Quad Pad |
| Polarity | Negative Ground |
| Efficiency | 60% |
| Weight | 25.4 lbs / 11.5 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 10.35 in / 263 mm |
| Remote Sense | Optional |
| Warranty *(US /Canada Only) |
3 year / 350,000 miles (new) 2 year / 250,000 miles (reman) |
36SI™ Brushless Type Alternator
| Performance Output | 12 Volts 170 Amps (100 Amps at idle) 24 Volts 105 Amps |
| Maximum Speed | 8,000 RPM Continuous 10,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 125°C / 257°F |
| Mounting | J180 Short Hinge Quad Pad |
| Polarity | Negative Ground (Standard) Isolated Ground (Available) |
| Efficiency | 68% |
| Weight | 25.4 lbs / 11.5 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 10.35 in / 263 mm |
| Remote Sense | Optional |
| Warranty *(US /Canada Only) |
3 year / 350,000 miles – New Service 2 year / 250,000 miles – Reman |
38SI™ Brushless Type Alternator
| Performance Output | 12 Volts 215 Amps (121 Amps at idle) |
| Maximum Speed | 8,000 RPM Continuous 10,000 RPM Intermittent |
| Rotation | Clockwise |
| Temperature Rating | 130°C / 266°F |
| Mounting | Pad |
| Polarity | Negative Ground |
| Efficiency | 72% |
| Weight | 30.4 lbs / 13.8 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 9.99 in / 253.8 mm |
| Remote Sense | Standard |
| Warranty *(US /Canada Only) |
3 year / unlimited miles |
40SI™ Brushless Type Alternator
| Performance Output | 12 Volts 240 Amps (160 Amps at idle) 12 Volts 275 Amps (180 Amps at idle) 12 Volts 300 Amps (190 Amps at idle) 12 Volts 320 Amps (190 Amps at idle) |
| Maximum Speed | 8,000 RPM Continuous 10,000 RPM Intermittent |
| Rotation | Clockwise |
| Temperature Rating | 240 & 275 Amp: 125°C / 257°F 300 & 320 Amp: 115°C / 239°F |
| Mounting | J180 Short Hinge J180 Long Hinge Pad |
| Polarity | Negative Ground |
| Efficiency | 72% |
| Weight | 31.0 lbs / 14.1 kg |
| Stator Diameter | 5.98 in / 152 mm |
| Length | 9.92 in / 252 mm |
| Remote Sense | Standard |
| Warranty *(US /Canada Only) |
3 year / unlimited miles |
55SI™ Brushless Type Alternator
| Performance Output | 12 Volts 430 Amps 24 Volts 250 & 275 Amps |
| Maximum Speed | 8,000 RPM Continuous 9,000 RPM Intermittent |
| Rotation | Clockwise |
| Temperature Rating | 12V 430A 93°C / 200°F 24V 250A 125°C / 257°F 24V 275A 110°C / 230°F |
| Mounting | Pad |
| Polarity | Negative Ground |
| Efficiency | 12 Volts 73% 24 Volts 80% |
| Weight | 43.2 lbs / 19.6 kg |
| Stator Diameter | 6.89 in / 175 mm |
| Length | 11.25 in / 285.9 mm |
| Remote Sense | Standard |
| Warranty *(US /Canada Only) |
3 year / unlimited miles |
50DN™ Alternator
| Performance Output | 24 Volts 270 Amps |
| Maximum Speed | 6,500 RPM Continuous 7,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 121°C/250°F |
| Mounting | Cradle |
| Polarity | Negative Ground |
| Efficiency | 78% |
| Weight | 100.0 lbs / 45.3 kg |
| Stator Diameter | 9.49 in / 241 mm |
| Length | 17.83 in / 453 mm |
| Drive End Bearing Size | 2.44 in / 72 mm |
| Remote Sense | Standard with 50VR Regulator |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
50DN+™ Alternator
| Performance Output | 24 Volts 450 Amps |
| Maximum Speed | 6,500 RPM Continuous 7,000 RPM Intermittent |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 121°C / 250°F |
| Mounting | Cradle |
| Polarity | Negative Ground |
| Efficiency | 78% |
| Weight | 109.7 lbs / 49.8 kg |
| Stator Diameter | 9.49 in / 241 mm |
| Length | 17.83 in / 453 mm |
| Drive End Bearing Size | 2.44 in / 72 mm |
| Remote Sense | Standard with 50VR Regulator |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
T1 Type Alternator
| Performance Output | 24 Volts 185 Amps |
| Maximum Speed | 7,000 RPM |
| Rotation | Clockwise Counterclockwise |
| Temperature Rating | 80°C / 176°F |
| Mounting | T1 Style |
| Polarity | Negative Ground |
| Efficiency | 60% |
| Weight | 36.2 lbs / 16.4 kg |
| Frame Diameter | 7.50 in / 190 mm |
| Length | 11.4 in / 289.3 mm |
| Warranty *(US /Canada Only) |
1 year / unlimited miles |
PT. PANEN RAYA DIESEL Menyediakan Alternator, Starting motor GENUINE dan OEM(Original Equipment Manufacture)untuk Engine,Kapal ,Alat Berat,Genset dan Truk untuk Merk sbb : KOMATSU,CATERPILLAR, KOBELCO,CUMMINS,HITACHI, PERKINS, VOLVO, HINO,JOHN DEERE,DEUTZ,dll
Merk STARTING MOTOR & ALTERNATOR :
– NIKKO Electric
– SAWAFUJI
– DELCOREMY
– BOSCH
– MITSUBISHI
– LUCAS
– RCP Canada
– PRESTOLITE Electric
– VALEO & lainya
Superior Performance for OE and Aftermarket Applications
Delco Remy alternators mean premium quality, increased efficiency, and measurable fuel savings for the commercial and off-road vehicle industry worldwide.
From brushless designs with fewer moving parts to remote sense to improve battery charge time, Delco Remy technology is second to none. We continue to leverage our experience to provide our OE and aftermarket partners with innovative solutions for today’s vehicle electric system challenges.
• Complete portfolio: From 70 to 450 Amp (24V).
• Efficient: Units are lighter weight and feature our proprietary stator design that uses less engine horsepower and translates to substantial fuel savings.
• Durable: Units are available with brushless design – fewer moving parts means less wear and longer life.
• Outstanding performance: Units are available with Remote Sense technology – which can reduce battery charge time by 50%.
—
